2" DUAL LITE Disc Filter - 40 Mesh, 400 Micron (Blue) - 132 GPM Max Flow

2" Arkal Dual Lite Disc Filter — 40 Mesh, 400 Micron (Blue)
OverviewArkal disc filters use a stack of grooved polypropylene rings to trap particles at each ring intersection. Flow passes through the compressed disc stack, and particles are caught at the many contact points throughout the depth of the filter — providing more effective filtration than simple screen filters at equivalent mesh ratings. The color-coded body identifies the filtration level at a glance.The Dual Lite design features twin filter elements in a single housing, doubling filter area and extending cleaning intervals. Suited for high-flow headers where sediment loads are significant. Polypropylene housing with NPT connections, rated to 150 PSI. Disc sets available separately.
Specifications

Model	F-DF200DL-040
Connection	2" NPT
Filtration	40 mesh / 400 micron
Color Code	Blue
Max Flow	132 GPM
Max Pressure	150 PSI
Series	Dual Lite
